Top / Capacitors / Ceramic / High Voltage / SPHT9501JA

Picture of SPHT9501JA

SPHT9501JA

High Energy Corp
Logo of High Energy Corp
If you are interested in pricing for larger quantities, please submit an RFQ.
Quantity:

SPHT9501JA Specifications

View SPHT9501JA Datasheet SPHT9501JA Data Sheet
Dielectric MaterialN750
Capacitance500 pF
fL (MHz)0.0753 MHz
fH (MHz)4.07 MHz
Smax (kVA)20 kVA
I max (Arms)16 Arms
Voltage DC13 kVdc
ClassClass 1
StylePower Disk
Case CodeSPHT9_A
DielectricCeramic
Capacitance Tolerance±5%

SPHT9501JA Case Dimensions

Height: 35.0000 mm
Diameter: 70.0000 mm
Picture of SPHT9501JA
